Vacuum Adapters

    Vacuum Adapters

    Vacuum adapters are portable connectors to connect evacuated tube quickly, using for connecting some vacuum fittings such as KF flanges and fittings, CF flanges and fittings and ISO flanges and fittings, to guarantee vacuum welding and material to reach the standard. Especially material is more strict with connecting to soft state corrugated pipe. If slight difference, maybe it can not reach the ideal vacuum effect after finishing connection when vacuum detection.

    • Tubulated Adapter
    • Pipe Adapter
    • Quick Disconnect Adapter
    • Reducing Adapter

    Features:

    • 1. Standard materials are in 304 and 316L stainless steel.
    • 2. Adapters are supplied with a machining finish. Other finishes are also available.
    • 3. Vacuum Range: ≥10-8Torr
    • 4. Seal Temperature Range:
      • Fluorocarbon FKM (Viton): -5℃~204℃ (23℉~399℉)
      • Silicon: -50℃~180℃(-58℉~356℉)
      • Buna-N (NBR): – 25℃~121℃ (-13℉~250℉)

    Applications:

    • 1. Connection exchange
    • 2. Use Teflon tape for sealing threaded joint.


    ISO-KF Tubulated Adaptor

    iso-kf-tubulated-adaptor

    Flange
    Size

    Tube
    Size

    Dimensions, in. (mm)

    A

    B

    C

    D

    ISO63×KF25

    1″

    3.74″ (95.0)

    1.57″ (40.0)

    1.65″ (42.0)

    1.00″ (25.4)

    ISO63×KF40

    1 1/2″

    3.74″ (95.0)

    2.17″ (55.0)

    1.65″ (42.0)

    1.50″ (38.1)

    ISO63×KF50

    2″

    3.74″ (95.0)

    2.95″ (75.0)

    1.65″ (42.0)

    2.00″ (50.8)

    ISO80×KF40

    1 1/2″

    4.33″ (110.0)

    2.17″ (55.0)

    1.65″ (42.0)

    1.50″ (38.1)

    ISO80×KF50

    2″

    4.33″ (110.0)

    2.95″ (75.0)

    1.65″ (42.0)

    2.00″ (50.8)

    ISO100×KF40

    1 1/2″

    5.12″ (130.0)

    2.17″ (55.0)

    1.65″ (42.0)

    1.50″ (38.1)

    ISO100×KF50

    2″

    5.12″ (130.0)

    2.95″ (75.0)

    1.65″ (42.0)

    2.00″ (50.8)


    KF Female Pipe Adaptor

    kf-female-pipe-adaptor

    Flange
    Size

    Tube
    Size

    Dimensions, in. (mm)

    Thread

    A

    B

    C

    KF16PT125

    3/4″

    0.75″ (19.1)

    0.98″ (25.0)

    0.67″ (17.0)

    1/8″BSPT

    KF25PT125

    1″

    1.00″ (25.4)

    0.98″ (25.0)

    0.75″ (19.0)

    1/8″BSPT

    KF40PT125

    1 1/2″

    1.50″ (38.1)

    0.98″ (25.0)

    1.26″ (32.0)

    1/8″BSPT

    KF50PT125

    2″

    2.00″ (50.8)

    0.98″ (25.0)

    1.81″ (46.0)

    1/8″BSPT

    KF16PT025

    3/4″

    0.75″ (19.1)

    0.98″ (25.0)

    0.67″ (17.0)

    1/4″BSPT

    KF25PT025

    1″

    1.00″ (25.4)

    0.98″ (25.0)

    0.75″ (19.0)

    1/4″BSPT

    KF40PT025

    1 1/2″

    1.50″ (38.1)

    0.98″ (25.0)

    1.26″ (32.0)

    1/4″BSPT

    KF50PT025

    2″

    2.00″ (50.8)

    0.98″ (25.0)

    1.81″ (46.0)

    1/4″BSPT

    Flange
    Size

    Tube
    Size

    Dimensions, in. (mm)

    Thread

    A

    B

    C

    KF16PT125

    3/4″

    0.75″ (19.1)

    0.98″ (25.0)

    0.67″ (17.0)

    1/8″NPT

    KF25PT125

    1″

    1.00″ (25.4)

    0.98″ (25.0)

    0.75″ (19.0)

    1/8″NPT

    KF40PT125

    1 1/2″

    1.50″ (38.1)

    0.98″ (25.0)

    1.26″ (32.0)

    1/8″NPT

    KF50PT125

    2″

    2.00″ (50.8)

    0.98″ (25.0)

    1.81″ (46.0)

    1/8″NPT

    KF16PT025

    3/4″

    0.75″ (19.1)

    0.98″ (25.0)

    0.67″ (17.0)

    1/4″NPT

    KF25PT025

    1″

    1.00″ (25.4)

    0.98″ (25.0)

    0.75″ (19.0)

    1/4″NPT

    KF40PT025

    1 1/2″

    1.50″ (38.1)

    0.98″ (25.0)

    1.26″ (32.0)

    1/4″NPT

    KF50PT025

    2″

    2.00″ (50.8)

    0.98″ (25.0)

    1.81″ (46.0)

    1/4″NPT


    ISO-ISO Conical Adaptor

    iso-iso-concentric-reducing-adapator

    Flange
    Size

    Tube Size

    C, in. (mm)

    T

    TX

    ISO80×ISO63

    3″

    2 1/2″

    4.13″ (105.0)

    ISO100×ISO63

    4″

    2 1/2″

    4.13″ (105.0)

    ISO100×ISO80

    4″

    3″

    4.13″ (105.0)


    CF Reducing Adaptor-Small Flange Rotatable

    cf-reducing-adapator-small-flange-rotatable

    Flange
    Size

    Tube
    Size

    A, in. (mm)

    CF40×CF16

    3/4″

    3.00″ (76.2)

    CF63×CF16

    3.00″ (76.2)

    CF63×CF40

    1 1/2″

    3.00″ (76.2)

    CF100×CF40

    3.00″ (76.2)

    CF100×CF63

    2 1/2″

    3.00″ (76.2)

    CF160×CF63

    3.00″ (76.2)

    CF160×CF100

    4″

    3.00″ (76.2)

    CF200×CF160

    6″

    4.75″ (120.6)


    *For more information of vacuum adapters, please feel free to contact us.
