A ASME flange is a method of connecting pipes, valves, pumps and other equipment to form a piping system. It also provides easy access for cleaning, inspection or modification. Flanges are usually welded or screwed. Flanged joints are made by bolting together two flanges with a gasket between them to provide a seal.

How to Select A ASME Flange

First,determine the applicable standard based on the pipe’s nominal diameter.Pipelines with a nominal diameter of 24 inches or less are subject to the ASME B16.5 standard,while large-diameter pipelines of 26 inches or more are subject to the ASME B16.47 standard.

Once the standard has been determined, select the structural design based on installation conditions and load requirements.

The selection of material depends on the chemical corrosiveness of the fluid and the operating temperature.Carbon steel is typically used for conventional, non-corrosive media,while stainless steel must be used for corrosive media,high-temperature applications,or sanitary-grade systems.

Next,the pressure class must be determined by cross-referencing the system’s maximum design pressure with the maximum operating temperature in the ASME pressure-temperature rating tables.

Finally,the appropriate flange face type must be selected based on gasket and sealing requirements.

As a professional manufacturer of ASTM flanges in China, feel free to contact us at any time. Our experts will conduct a comprehensive analysis of the conditions your piping system faces and provide you with the best solutions.

Our Reliable ASME Flanges

Flanges

Flanges

Flanges

Flanges

Flanges

Flanges

Flanges

Flanges

Flanges

Flanges

Flange Material

What Material We Do

Stainless Steel

ASTM A182 F304, F304L,F316, F316L, 316Ti, F317L, F321,F321H, F310H, F347H, N08904, F44 etc.
ASTM A/SA182 F51, F53, F55, F59, F60

Titanium & Aluminum

ASTM SB381 F1, F2, F3, F5, F7, F9, F12 etc.
ASTM B247 GR 6061, GR.5083 etc.

Other Alloys

ASTM A105,A105N; St37.2, C22.8;
ASTM A182 F11, F12, F22, F5, F91;
ASTM A350 LF2, LF3;
ASTM A694 F42, F46, F48, F50, F52, F56, F60, F65, F70 etc.

ASME Flange B16.5-1996 and B16.47-1996

ASME/ANSI B16.5-1996 and B16.47-1996
Tolerances on flange dimensions (ASME/ANSI B16.5 and B16.7, and MSS SP-44)
Dimension	Range	Tolerance
Dimension	Range	in	mm
General and Blind Flanges(For blind flange dimendions see page 8-23 for B16.5, page8-46 for B16.47 Series A/ MSS SP-44 and page 8-51 for B16.47 Series B/ API 605):
G(raised face diameter)	≤NPS 24	±0.03	±0.76
	≥NPS 26,with 0.06 in raised face	±0.08	±2.03
	≥NPS 26,with 0.25 in raised face	±0.04	±1.02
I(bolt hole diameter)	All	No tolerance in B16.5 or B 16.47
J(bolt circle diameter)	All	±0.06	±1.52
Center to center of adjacent bolt holes	All	±0.03	±0.76
Eccenticity of bolt circle and machined facing diameters	≤NPS 2½	±0.03	±0.76
Eccenticity of bolt circle and machined facing diameters	≥NPS 3	±0.06	±1.52
Weld Neck Flanges1 (For dimensions see page 8-10 for B 16.5, page 8-46 for B16.47 Series A/ MSS SP-44 and page 8-51 for B16.47 Series B/ API 605):
D(overall length)	≤NPS 4	﹢0.06	﹢1.52
	NPS 5 to 10	﹢0.06,﹣0.12	﹢1.52,﹣3.05
	NPS 12 to 24	﹢0.12,﹣0.18	﹢3.05,﹣4.57
	≥NPS 26	±0.19	±4.83
Thickness of hub	All	＞87.5% of pipe nominal wall thickness
Slip on(see page 8-17),Lap Joint(see page8-32) and Socket Welding(see page 8-30 for dimensions) Flanges:
B(inside diameter,or bore)	≤NPS10	﹢0.03,﹣0.0	﹢0.76,﹣0.0
B(inside diameter,or bore)	≥NPS12	﹢0.06,﹣0.0	﹢1.52,﹣0.0
Threaded Flanges (see page 8-40 for dimensions):
B(counterbore) (Not applicable for Class 150 lb	≤NPS10	﹢0.03,﹣0.0	﹢0.76,﹣0.0
B(counterbore) (Not applicable for Class 150 lb	≥NPS12	﹢0.06,﹣0.0	﹢1.52,﹣0.0

*If you’re browsing on a tablet or phone, you can swipe left or right to view this table.

Learn More About Kaysuns

Kaysuns supplies ASME flanges manufactured from stainless steel, alloy steel, carbon steel, and other materials. If you have specific material requirements, please don’t hesitate to contact us.

ASME Flange B 16.5-2009 Specifications

Class 150

CLASS 150			FLANGE THICKNESS		LTB				DRILLING DATA			CLASS 150
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANGE MIN		BOSSED LENGTH	WELD NECK LENGTH *	LAP JOINT LENGTH	LONG WELD NECK LENGTH	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES	NOMINAL PIPE SIZE
MM	INCH	OD	T	T1	L	L1	L2	L3	PCD	H	#	MM	INCH
15	½	90	9.6	11.2	16	46	16	229	60.3	16	4	15	½
20	¾	100	11.2	12.7	16	51	16	229	69.9	16	4	20	¾
25	1	110	12.7	14.3	17	54	17	229	79.4	16	4	25	1
32	1 1/4	115	14.3	15.9	21	56	21	229	88.9	16	4	32	1 1/4
40	1 ½	125	15.9	17.5	22	60	22	229	98.4	16	4	40	1 ½
50	2	150	17.5	19.1	25	62	25	229	120.7	20	4	50	2
65	2 ½	180	20.7	22.3	29	68	29	229	139.7	20	4	65	2 ½
80	3	190	22.3	23.9	30	68	30	229	152.4	20	4	80	3
90	3 ½	215	22.3	23.9	32	70	32	229	177.8	20	8	90	3 ½
100	4	230	22.3	23.9	33	75	33	229	190.5	20	8	100	4
125	5	255	22.3	23.9	36	87	36	305	215.9	23	8	125	5
150	6	280	23.9	25.4	40	87	40	305	241.3	23	8	150	6
200	8	345	27	28.6	44	100	44	305	298.5	23	8	200	8
250	10	405	28.6	30.2	49	100	49	305	362	26	12	250	10
300	12	485	30.2	31.8	56	113	56	305	431.8	26	12	300	12
350	14	535	33.4	35	57	125	79	305	476.3	29	12	350	14
400	16	595	35	36.6	64	125	87	305	539.8	29	16	400	16
450	18	635	38.1	39.7	69	138	97	305	577.9	32	16	450	18
500	20	700	41.3	42.9	73	143	103	305	635	32	20	500	20
600	24	815	46.1	47.7	83	151	111	305	749.3	25	20	600	24

Class 300

CLASS 300		FLANGE OUTSIDE DIAMETER	FLANGE THICKNESS		LTB				DRILLING DATA			CLASS 300
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANCE MIN	THICKNESS OF LAP MIN	BOSSED LENGTH	WELD NECK LENGTH	LAP JOINT LENGTH	LONG WELD NECK LENGTH	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES	NOMINAL PIPE SIZE
MM	INCH	OD	T	T1	L	L1	L2	L3	PCD	H	#	MM	INCH
15	½	95	12.7	14.3	21	51	22	229	66.7	16	4	15	½
20	¾	115	14.3	15.9	24	56	25	229	82.6	20	4	20	¾
25	1	125	15.9	17.5	25	60	27	229	88.9	20	4	25	1
32	1 1/4	135	17.5	19.1	25	64	27	229	98.4	20	4	32	1 1/4
40	1 ½	155	19.1	20.7	29	67	30	229	114.3	23	4	40	1 ½
50	2	165	20.7	22.3	32	68	33	229	127	20	8	50	2
65	2 ½	190	23.9	25.4	37	75	38	229	149.2	23	8	65	2 ½
80	3	210	27	28.6	41	78	43	229	168.3	23	8	80	3
90	3 ½	230	28.6	30.2	43	79	44	229	184.2	23	8	90	3 ½
100	4	255	30.2	31.8	46	84	48	229	200	23	8	100	4
125	5	280	33.4	35	49	97	51	305	235	23	8	125	5
150	6	320	35	36.6	51	97	52	305	269.9	23	12	150	6
200	8	380	39.7	41.3	60	110	62	305	330.2	26	12	200	8
250	10	445	46.1	47.7	65	116	95	305	387.4	29	16	250	10
300	12	520	49.3	50.8	71	129	102	305	450.8	32	16	300	12
350	14	585	52.4	54	75	141	111	305	514.4	32	20	350	14
400	16	650	55.6	57.2	81	144	121	305	571.5	35	20	400	16
450	18	710	58.8	60.4	87	157	130	305	628.6	35	24	450	18
500	20	775	62	63.5	94	160	140	305	685.8	35	24	500	20
600	24	915	68.3	69.9	105	167	152	305	812.8	42	24	600	24

Class 400

CLASS 400		FLANGE OUTSIDE DIAMETER	FLANGE THICKNESS	LTB				DRILLING DATA			CLASS400
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANCE MIN	BOSSED LENGTH	WELD NECK LENGTH *	LAP JOINT LENGTH	LONG WELD NECK LENGTH	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES	NOMINAL PIPE SIZE
MM	INCH	OD	T & T1	L	L1	L2	L3	PCD	H	#	MM	INCH
15	½	95	14.3	29	59	22	229	66.7	16	4	5	½
20	3/4	115	15.9	32	64	25	229	82.6	20	4	20	3/4
25	1	125	17.5	34	69	27	229	88.9	20	4	25	1
32	1 1/4	135	20.7	36	74	29	229	98.4	20	4	32	1 1/4
40	1 1/2	155	22.3	39	77	32	229	114.3	22	4	40	1 1/2
50	2	165	25.4	44	80	37	229	127	20	8	50	2
65	2 1/2	190	28.6	48	86	41	229	149.2	22	8	65	2 1/2
80	3	210	31.8	53	90	46	229	168.3	22	8	80	3
90	3 1/2	230	35	56	93	49	229	184.2	26	8	90	3 1/2
100	4	255	35	58	96	51	229	200	26	8	100	4
125	5	280	38.1	61	109	54	305	235	26	8	125	5
150	6	320	41.3	64	110	57	305	269.9	26	12	150	6
200	8	380	47.7	75	124	68	305	330	30	12	200	8
250	10	445	54	80	131	102	305	387.4	32	16	250	10
300	12	520	57.2	86	144	108	305	450.8	35	16	300	12
350	14	585	60.4	91	156	117	305	514.4	35	20	350	14
400	16	650	63.5	101	159	127	305	571.5	38	20	400	16
450	18	710	66.7	105	172	137	305	628.6	38	24	450	18
500	20	775	69.9	109	175	146	305	685.8	42	24	500	20
600	24	915	76.2	121	182	159	305	812.8	48	24	600	24

Class 600

CLASS 600		FLANGE OUTSIDE DIAMETER	FLANGE THICKNESS	LTB				DRILLING DATA			CLASS 600
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANCE MIN	BOSSED LENGTH	WELD NECK LENGTH *	LAP JOINT LENGTH	LONG WELD NECK LENGTH	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES	NOMINAL PIPE SIZE
MM	INCH	OD	T & T1	L	L1	L2	L3	PCD	H	#	MM	INCH
15	½	95	14.3	29	59	22	229	66.7	16	4	15	½
20	3/4	115	15.9	32	64	25	229	82.6	20	4	20	3/4
25	1	125	17.5	34	69	27	229	88.9	20	4	25	1
32	1 1/4	135	20.7	36	74	29	229	98.4	20	4	32	1 1/4
40	1 1/2	155	22.3	39	77	32	229	114.3	22	4	40	1 1/2
50	2	165	25.4	44	80	37	229	127	20	8	50	2
65	2 1/2	190	28.6	48	86	41	229	149.2	22	8	65	2 1/2
80	3	210	31.8	53	90	46	229	168.3	22	8	80	3
90	3 1/2	230	35	56	93	49	229	184.2	26	8	90	3 1/2
100	4	275	38.1	61	109	54	229	215.9	26	8	100	4
125	5	330	44.5	67	121	60	305	266.7	29	8	125	5
150	6	355	47.7	74	124	67	305	292.1	29	12	150	6
200	8	420	55.6	83	140	76	305	349.2	32	12	200	8
250	10	510	63.5	93	159	111	305	431.8	35	16	250	10
300	12	560	66.7	99	163	117	305	489	35	20	300	12
350	14	605	69.9	101	172	127	305	527	38	20	350	14
400	16	685	76.2	113	185	140	305	603.2	42	20	400	16
450	18	745	82.6	124	191	152	305	654	45	20	450	18
500	20	815	88.9	134	197	165	305	723.9	45	24	500	20
600	24	940	101.6	147	210	184	305	838.2	51	24	600	24

Class 900

CLASS 900		FLANGE OUTSIDE DIAMETER	FLANGE THICKNESS	LTB				DRILLING DATA			CLASS 900
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANCE MIN	BOSSED LENGTH	WELD NECK LENGTH *	LAP JOINT LENGTH	LONG WELD NECK LENGTH	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES	NOMINAL PIPE SIZE
MM	INCH	OD	T & T1	L	L1	L2	L3	PCD	H	#	MM	INCH
15	½	120	22.5	39.0	67	32	229	82.6	22	4	5	1 ½
20	3/4	130	25.5	42.0	77	35	229	88.9	22	4	20	3/4
25	1	150	29	48.0	80	41	229	101.6	26	4	25	1
32	1 1/4	160	29	48.0	80	41	229	111.1	26	4	32	1 1/4
40	1 1/2	180	32	51.0	90	44	229	123.8	29	4	40	1 1/2
50	2	215	38.5	64.0	109	57	229	165.1	26	8	50	2
65	2 1/2	245	41.5	71.0	112	64	229	190.5	29	8	65	2 1/2
80	3	265	38.1	61.0	109	54	229	190.5	26	8	80	3
100	4	290	44.5	77.0	121	70	229	235.0	32	8	100	4
125	5	350	50.8	86.0	134	79	305	279.4	35	8	125	5
150	6	380	55.6	93.0	147	86	305	317.5	32	12	150	6
200	8	470	63.5	109.0	169	114	305	393.7	38	12	200	8
250	10	545	69.9	115.0	191	127	305	469.9	38	16	250	10
300	12	610	79.4	124.0	207	143	305	533.4	38	20	300	12
350	14	640	85.8	137.0	220	156	305	558.8	42	20	350	14
400	16	705	88.9	140.0	223	165	305	616.0	45	20	400	16
450	18	785	101.6	159.0	236	190	305	685.8	51	20	450	18
500	20	855	108	166.0	255	210	305	749.3	54	20	500	20
600	24	1040	139.7	210.0	299	267	305	901.7	67	20	600	24

Class 1500

CLASS 1500		FLANGE OUTSIDE DIAMETER	FLANGE THICKNESS	LTB				DRILLING DATA			CLASS 1500
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANCE MIN	BOSSED LENGTH	WELD NECK LENGTH *	LAP JOINT LENGTH	LONG WELD NECK LENGTH	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES	NOMINAL PIPE SIZE
MM	INCH	OD	T & T1	L	L1	L2	L3	PCD	H	#	MM	INCH
15	½	120	22.5	39.0	67	32	229	82.6	22	4	15	½
20	3/4	130	25.5	42.0	77	35	229	88.9	22	4	20	3/4
25	1	150	29	48.0	80	41	229	101.6	26	4	25	1
32	1 1/4	160	29	48.0	80	41	229	111.1	26	4	32	1 1/4
40	1 1/2	180	32	51.0	90	44	229	123.8	29	4	40	1 1/2
50	2	215	38.5	64.0	109	57	229	165.1	26	8	50	2
65	2 1/2	245	41.5	71.0	112	64	229	190.5	29	8	65	2 1/2
80	3	265	48		124	73	229	203.2	32	8	80	3
100	4	310	54		131	90	229	241.3	35	8	100	4
125	5	375	73.5		163	105	305	292.1	42	8	125	5
150	6	395	83		178	119	305	317.5	38	12	150	6
200	8	485	92		220	143	305	393.7	45	12	200	8
250	10	585	108		261	178	305	482.6	51	12	250	10
300	12	675	124		290	219	305	571.5	54	16	300	12
350	14	750	133.5		305	241	305	635.0	60	16	350	14
400	16	825	146.5		318	260	311	704.8	67	16	400	16
450	18	915	162		334	276	327	774.7	73	16	450	18
500	20	985	178		363	292	356	831.8	79	16	500	20
600	24	1170	203.5		413	330	406	990.6	92	16	600	24

Class 2500

CLASS 2500		FLANGE OUTSIDE DIAMETER	FLANGE THICKNESS	LTB				DRILLING DATA			CLASS 2500
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF FLANCE MIN	BOSSED LENGTH	WELD NECK LENGTH *	LAP JOINT LENGTH	LONG WELD NECK LENGTH	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLT HOLES	NOMINAL PIPE SIZE
MM	INCH	OD	T & T1	L	L1	L2	L3	PCD	H	#	MM	INCH
15	½	135	30.2	47.0	80	40	229	88.9	22	4	15	½
20	3/4	140	31.8	50.0	86	43	229	95.2	22	4	20	3/4
25	1	160	35	55.0	96	48	229	108	26	4	25	1
32	1 1/4	185	38.1	59.0	102	52	229	130.2	29	4	32	1 1/4
40	1 1/2	205	44.5	67.0	118	60	229	146	32	4	40	1 1/2
50	2	235	50.9	77.0	134	70	229	171.4	29	8	50	2
65	2 1/2	265	57.2	86.0	150	79	229	196.8	32	8	65	2 1/2
80	3	305	66.7		175	92	229	228.6	35	8	80	3
100	4	355	76.2		197	108	305	273	42	8	100	4
125	5	420	92.1		235	130	305	323.8	48	8	125	5
150	6	485	108		280	152	305	368.3	54	8	150	6
200	8	550	127		324	178	305	438.2	54	12	200	8
250	10	675	165.1		426	229	406	539.8	67	12	250	10
300	12	760	184.2		471	254	406	619.1	73	12	300	12

Discover Kaysuns’ stainless steel flange manufacturing process right away and experience our state-of-the-art manufacturing equipment. Kaysuns is a reliable Chinese manufacturer of stainless steel flanges, renowned both domestically and internationally, earning consistent praise from customers and serving many repeat clients.

ASME Flange B 16.47-2006 Series A Specifications

Class 150

CLASS 150 Series.A		FLANGE OUTSIDE DIAMETER	FLANGE THICKNESS		LTB	DRILLING DATA			NOMINAL PIPE SIZE
NOMINAL PIPE SIZE		FLANGE OUTSIDE DIAMETER	THICKNESS OF W/N MIN	THICKNESS OF BLIND MIN	WELD NECK LENGTH	PITCH CIRCLE DIAMETER	BOLT HOLE DIAMETER	NUMBER OF BOLTS HOLES	NOMINAL PIPE SIZE
MM	INCH	OD	T	T1	L	PCD	H	#	MM	INCH
650	26	870	66.7	66.7	119	806.4	1(3/8)	24	650	26
700	28	925	69.9	69.9	124	863.6	1(3/8)	28	700	28
750	30	985	73.1	73.1	135	914.4	1(3/8)	28	750	30
800	32	1060	79.4	79.4	143	977.9	1(5/8)	28	800	32
850	34	1110	81	81	148	1028.7	1(5/8)	32	850	34
900	36	1170	88.9	88.9	156	1085.8	1(5/8)	32	900	36
950	38	1240	85.8	85.8	156	1149.4	1(5/8)	32	950	38
1000	40	1290	88.9	88.9	162	1200.2	1(5/8)	36	1000	40
1050	42	1345	95.3	95.3	170	1257.3	1(5/8)	36	1050	42
1100	44	1405	100.1	100.1	176	1314.4	1(5/8)	40	1100	44
1150	46	1455	101.6	101.6	184	1365.2	1(5/8)	40	1150	46
1200	48	1510	106.4	106.4	191	1422.4	1(5/8)	44	1200	48
1250	50	1570	109.6	109.6	202	1479.6	1(7/8)	44	1250	50
1300	52	1625	114.3	114.3	208	1536.7	1(7/8)	44	1300	52
1350	54	1685	119.1	119.1	214	1593.8	1(7/8)	44	1350	54
1400	56	1745	122.3	122.3	227	1651	1(7/8)	48	1400	56
1450	58	1805	127	127	233	1708.2	1(7/8)	48	1450	58
1500	60	1855	130.2	130.2	238	1759	1(7/8)	52	1500	60

Ring Groove Class 300 - 900 (Ring Joint Dimensions Series A Class 300, 600, 900)

NOMINAL PIPE SIZE FOR CLASS			GROOVE NUMBER	PITCH DIAMETER	DEPTH	WIDTH	RADIUS AT BASE	DIAMETER RF SECTION
300	600	900	GROOVE NUMBER	A	B	C	D	E
650(26″)	650(26″)		R93	749.3	0.5	0.781	1.5	810
700(28″)	700(28″)		R94	800.1	0.5	0.781	1.5	861
750(30″)	750(30″)		R95	857.25	0.5	0.781	1.5	917
800(32″)	800(32″)		R96	914.4	0.562	0.906	1.5	984
850(34″)	850(34″)		R97	965.2	0.562	0.906	1.5	1035
900(36″)	900(36″)		R98	1022.35	0.562	0.906	1.5	1092
		650(26″)	R100	749.3	0.688	1.188	2.3	832
		700(28″)	R101	800.1	0.688	1.312	2.3	889
		750(30″)	R102	857.25	0.688	1.312	2.3	946
		800(32″)	R103	914.4	0.688	1.312	2.3	1003
		850(34″)	R104	965.2	0.812	1.438	2.3	1067
		900(36″)	R105	1022.35	0.812	1.438	2.3	1124

ASME B-16.48 2005 Spectacles, Spades & Spacers

CLASS 150
Nominal Pipe Size		Diam -eter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	Diam -eter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	ID	OD	A	T	B
15	½	16	45	60	3	38
20	3/4	21	54	70	3	38
25	1	27	64	80	3	38
32	1 1/4	42	73	90	6.4	38
40	1 1/2	48	83	100	6.4	38
50	2	61	102	120	6.4	51
65	2 1/2	73	107	140	6.4	51
80	3	89	133	150	6.4	64
90	3 1/2	102	159	175	9.7	64
100	4	114	172	190	9.7	64
125	5	141	194	215	9.7	76
150	6	168	219	240	12.7	76
200	8	219	276	300	12.7	76
250	10	273	337	360	15.7	102
300	12	324	406	430	19.1	102
350	14	356	448	475	19.1	108
400	16	406	511	460	22.4	108
450	18	457	546	580	25.4	114
500	20	508	603	635	28.4	121
600	24	610	714	750	31.8	140

CLASS 300
Nominal Pipe Size		Inside Diameter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	Inside Diameter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	ID	OD	A	T	B
15	½	16	51	65	6.4	38
20	3/4	21	64	80	6.4	38
25	1	27	70	90	6.4	38
32	1 1/4	42	79	100	6.4	38
40	1 1/2	48	92	115	6.4	38
50	2	61	108	125	9.7	51
65	2 1/2	73	127	150	9.7	51
80	3	89	146	170	9.7	64
90	3 1/2	102	162	185	12.7	64
100	4	114	178	200	12.7	64
125	5	141	213	235	15.7	76
150	6	168	248	270	15.7	76
200	8	219	305	330	22.4	76
250	10	273	359	385	25.4	102
300	12	324	419	450	28.5	102
350	14	356	483	515	31.8	108
400	16	406	536	570	38.1	108
450	18	457	594	630	41.1	114
500	20	508	651	685	44.5	121
600	24	610	772	810	50.8	140

CLASS 600
Nominal Pipe Size		Inside Diameter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	Inside Diameter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	ID	OD	A	T	B
15	½	16	51	65	6.4	38
20	3/4	21	64	80	6.4	38
25	1	27	70	90	6.4	57
32	1 1/4	37	79	100	9.7	57
40	1 1/2	43	92	115	9.7	67
50	2	55	108	125	9.7	57
65	2 1/2	67	127	150	12.7	67
80	3	83	146	170	12.7	67
90	3 1/2	96	159	185	15.7	76
100	4	108	191	215	15.7	76
125	5	135	238	265	19.1	86
150	6	162	264	290	22.4	86
200	8	212	318	350	28.4	95
250	10	265	397	430	35.1	105
300	12	315	454	490	41.1	105
350	14	346	489	525	44.5	114
400	16	397	562	605	50.8	124
450	18	448	610	655	53.9	133
500	20	497	680	725	63.5	133
600	24	597	787	840	73.2	152

CLASS 900
Nominal Pipe Size		Diam -eter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	Diam -eter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	ID	OD	A	T	B
15	½	16	60	80	6.4	38
20	3/4	21	67	90	6.4	41
25	1	27	76	100	6.4	57
32	1 1/4	37	86	110	9.7	57
40	1 1/2	43	95	125	9.7	67
50	2	55	140	165	12.7	57
65	2 1/2	67	162	190	12.7	67
80	3	83	165	190	15.7	67
100	4	108	203	235	19.1	76
125	5	135	244	280	22.4	86
150	6	162	286	320	25.4	86
200	8	212	356	395	35.1	95
250	10	265	432	470	41.1	105
300	12	315	495	535	47.8	105
350	14	346	518	560	53.8	114
400	16	397	572	615	60.5	124
450	18	448	635	685	66.5	133
500	20	497	696	750	73.2	133
600	24	597	835	900	88.9	152

CLASS 1500
Nominal Pipe Size		Inside Diameter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	Inside Diameter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	ID	OD	A	T	B
15	½	16	61	80	6.4	38
20	3/4	21	67	90	9.7	41
25	1	27	76	100	9.7	64
32	1 1/4	35	86	110	9.7	64
40	1 1/2	41	95	125	12.7	70
50	2	53	140	165	12.7	70
65	2 1/2	63	162	190	15.7	76
80	3	78	172	205	19.1	76
100	4	102	206	240	22.4	89
125	5	128	251	290	28.4	89
150	6	154	279	320	35.1	89
200	8	203	349	395	41.1	102
250	10	255	432	480	50.8	114
300	12	303	518	570	60.5	114
350	14	333	575	635	66.5	127
400	16	381	638	705	76.2	133
450	18	429	702	775	85.9	146
500	20	478	752	830	95.3	152
600	24	575	899	990	111.3	178

CLASS 2500
Nominal Pipe Size		Inside Diameter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	Inside Diameter	Outside Diameter	Centre Line Spacing	Thickness Min	Web Width
MM	INCH	ID	OD	A	T	B
15	½	16	67	90	9.7	38
20	3/4	21	73	95	9.7	41
25	1	27	83	110	9.7	64
32	1 1/4	35	102	130	12.7	64
40	1 1/2	41	114	145	15.7	70
50	2	53	143	170	15.7	70
65	2 1/2	63	165	195	19.1	76
80	3	78	194	230	22.4	76
100	4	102	232	275	28.4	89
125	5	128	276	325	35.1	89
150	6	154	314	370	41.1	89
200	8	198	384	440	53.8	102
250	10	248	473	540	66.5	114
300	12	289	546	620	79.2	114
350	14	N/A	N/A	N/A	N/A	N/A
400	16	N/A	N/A	N/A	N/A	N/A
450	18	N/A	N/A	N/A	N/A	N/A
500	20	N/A	N/A	N/A	N/A	N/A
600	24	N/A	N/A	N/A	N/A	N/A

Get A Free Quote >>>>>>>>>>>>>>>>>>>>

ASME Flange

Get A Free Quote

How to Select A ASME Flange

Table of Contents

Our Reliable ASME Flanges

What Material We Do

Stainless Steel

Titanium & Aluminum

Other Alloys

ASME Flange B16.5-1996 and B16.47-1996

ASME Flange B 16.5-2009 Specifications

Class 150

Class 300

Class 400

Class 600

Class 900

Class 1500

Class 2500

ASME Flange B 16.47-2006 Series A Specifications

Class 150

Ring Groove Class 300 - 900 (Ring Joint Dimensions Series A Class 300, 600, 900)

ASME B-16.48 2005 Spectacles, Spades & Spacers

Your Reliable Resources of

Stainless Steel, Nickel Alloy, Titanium Alloy etc.

Products

Terms

About

Kaysuns

Welcome to contact us

Supplying of
Stainless & Alloy Piping Material

Get a Free Quote Now

Get a free Quote now

Do you want to learn more? Contact us

We will reply you in 24 hours. Thank you!

ASME Flange

Get A Free Quote

How to Select A ASME Flange

Table of Contents

Our Reliable ASME Flanges

What Material We Do

Stainless Steel

Titanium & Aluminum

Other Alloys

ASME Flange B16.5-1996 and B16.47-1996

ASME Flange B 16.5-2009 Specifications

Class 150

Class 300

Class 400

Class 600

Class 900

Class 1500

Class 2500

ASME Flange B 16.47-2006 Series A Specifications

Class 150

Ring Groove Class 300 - 900 (Ring Joint Dimensions Series A Class 300, 600, 900)

ASME B-16.48 2005 Spectacles, Spades & Spacers

Welcome to contact us

Supplying of Stainless & Alloy Piping Material

Get a Free Quote Now

Get a free Quote now

Do you want to learn more? Contact us

We will reply you in 24 hours. Thank you!

Supplying of
Stainless & Alloy Piping Material
